FB61 MANU P04 : Tilt Table manual mode |
|
|
|
|
|
Netzwerk 1: Fault transfer 00_15 L "DI MAIN P04".FLT."1_fault_00_15" T #"1_FAULT_00_15" L "DI MAIN P04".FLT."2_fault_00_15" T #"2_FAULT_00_15" |
|
|
|
|
|
Netzwerk 2: 1_X0 VC810 Tilt table Enable U "E00 DC24L4 E9003" U "E04 HC812 B46 HP" UN "DI MAIN P04".FLT."1_fault_00_15".%X0 = "HMI KEY".P04.VC810.Enbl_WP = "HMI KEY".P04.VC810.Enbl_HP |
|
|
|
|
|
Netzwerk 3: 1_X1 HC812 Stow pin Enable U "E00 DC24L4 E9003" UN "DI MAIN P04".FLT."1_fault_00_15".%X2 = "HMI KEY".P04.HC812.Enbl_HP = "HMI KEY".P04.HC812.Enbl_WP |
|
|
|
|
|
Netzwerk 4: 1_X2
|
|
|
|
|
|
Netzwerk 5: P04 Monitoring manual operation *** UN #ST_MANU BEB
U #HMI_HOM_POS U "M01 HomPos" FP #HMI_HomPos_FP = "M03 Init"
U #SUPPORT_MANU // in this system irrelevant BEB |
|
|
|
|
|
Netzwerk 6: VC810 Set point speed U "HMI KEY".P04.VC810.F14_set_rapid_traverse R "HMI KEY".P04.VC810.Support.Speed_WP_on R "HMI KEY".P04.VC810.Support.Speed_HP_on SPB m073 U "HMI KEY".P04.VC810.F10_set_speed_HP SPBN m070 S "HMI KEY".P04.VC810.Support.Speed_HP_on R "HMI KEY".P04.VC810.Support.Speed_WP_on R "HMI KEY".P04.VC810.Support.Pressure_WP_on R "HMI KEY".P04.VC810.Support.Pressure_HP_on m077: L "DI OUT P04".VC810.Support.speed_HP T "DI OUT PRS".MaDa.Slider_ControlValue BEA m070: U "HMI KEY".P04.VC810.Support.Speed_HP_on SPBN m071 L "DI OUT P04".VC810.Support.SavePos L "DI OUT P04".VC810.Support.speed_HP T "DI OUT P04".VC810.Support.SavePos XOW SPZ m076 L "DI OUT P04".VC810.Support.speed_HP UW O <>0 O ==0 SPB m077 BEA m076: L "DI OUT PRS".MaDa.Slider_ControlValue T "DI OUT P04".VC810.Support.speed_HP
m071: U "HMI KEY".P04.VC810.F11_set_speed_WP SPBN m072 S "HMI KEY".P04.VC810.Support.Speed_WP_on R "HMI KEY".P04.VC810.Support.Speed_HP_on R "HMI KEY".P04.VC810.Support.Pressure_WP_on R "HMI KEY".P04.VC810.Support.Pressure_HP_on
m075: L "DI OUT P04".VC810.Support.speed_WP T "DI OUT PRS".MaDa.Slider_ControlValue BEA m072: U "HMI KEY".P04.VC810.Support.Speed_WP_on SPBN m073 L "DI OUT P04".VC810.Support.SavePos L "DI OUT P04".VC810.Support.speed_WP T "DI OUT P04".VC810.Support.SavePos XOW SPZ m074 L "DI OUT P04".VC810.Support.speed_WP UW O <>0 O ==0 SPB m075 BEA m074: L "DI OUT PRS".MaDa.Slider_ControlValue T "DI OUT P04".VC810.Support.speed_WP |
|
|
|
|
|
Netzwerk 7: VC810 Set point pressure m073: U "HMI KEY".P04.VC810.F12_set_pressure_HP SPBN m080 S "HMI KEY".P04.VC810.Support.Pressure_HP_on R "HMI KEY".P04.VC810.Support.Pressure_WP_on R "HMI KEY".P04.VC810.Support.Speed_WP_on R "HMI KEY".P04.VC810.Support.Speed_HP_on m083: L "DI OUT P04".VC810.Support.pressure_HP T "DI OUT PRS".MaDa.Slider_ControlValue BEA m080: U "HMI KEY".P04.VC810.Support.Pressure_HP_on SPBN m081 L "DI OUT P04".VC810.Support.SavePos L "DI OUT P04".VC810.Support.pressure_HP T "DI OUT P04".VC810.Support.SavePos XOW SPZ m082 L "DI OUT P04".VC810.Support.pressure_HP UW O <>0 O ==0 SPB m083 BEA m082: L "DI OUT PRS".MaDa.Slider_ControlValue T "DI OUT P04".VC810.Support.pressure_HP
m081: U "HMI KEY".P04.VC810.F13_set_pressure_WP SPBN m084 S "HMI KEY".P04.VC810.Support.Pressure_WP_on R "HMI KEY".P04.VC810.Support.Pressure_HP_on R "HMI KEY".P04.VC810.Support.Speed_WP_on R "HMI KEY".P04.VC810.Support.Speed_HP_on m087: L "DI OUT P04".VC810.Support.pressure_WP T "DI OUT PRS".MaDa.Slider_ControlValue BEA m084: U "HMI KEY".P04.VC810.Support.Pressure_WP_on SPBN m085 L "DI OUT P04".VC810.Support.SavePos L "DI OUT P04".VC810.Support.pressure_WP T "DI OUT P04".VC810.Support.SavePos XOW SPZ m086 L "DI OUT P04".VC810.Support.pressure_WP UW O <>0 O ==0 SPB m087 BEA m086: L "DI OUT PRS".MaDa.Slider_ControlValue T "DI OUT P04".VC810.Support.pressure_WP |
|
|
|
|
|
Netzwerk 8: HC812 Stow pin Execute manual operation m085: U "HMI KEY".P04.HC812.F1_HP S "HMI KEY".P04.HC812.Manual_Jog_output_HP ON "HMI KEY".P04.HC812.Enbl_HP O "HMI KEY".P04.HC812.F2_WP R "HMI KEY".P04.HC812.Manual_Jog_output_HP |
|
|
|
|
|
Netzwerk 9: VCl810 Execute manual operation U "HMI KEY".P04.VC810.F1_HP U "HMI KEY".P04.VC810.Enbl_HP = "HMI KEY".P04.VC810.Manual_Jog_output_HP
U "HMI KEY".P04.VC810.F2_WP U "HMI KEY".P04.VC810.Enbl_WP = "HMI KEY".P04.VC810.Manual_Jog_output_WP |
|
|
FB66 OUT P04 : Tilt Table outputs |
|
|
|
|
|
Netzwerk 1: P04 Pre-Setting O "M00 Auto CmpltMa run" O "M03 RunHomPos" = #tmp_seq_cmd_onoff |
|
|
|
|
|
Netzwerk 2: HC812 Stow pin tilt table O #VC810.Support.CMD_HP O #VC810.Support.CMD_WP U #tmp_seq_cmd_onoff O "HMI KEY".P04.HC812.Manual_Jog_output_HP = "A04 HC812 Y812 WP" |
|
|
|
|
|
Netzwerk 3: VC810 Tilt table WP U "M04 VC810 SEQ run WP" U #tmp_seq_cmd_onoff O "HMI KEY".P04.VC810.Manual_Jog_output_WP = #VC810.Support.CMD_WP
U #VC810.Support.CMD_WP U "E04 HC812 B46 HP" UN "E04 VC810 B41 WP" L #VC810.Support.DlyOnOff SA "T04 VC810 WP SA" U "T04 VC810 WP SA" = "A04 VC810 Y810 WP" |
|
|
|
|
|
Netzwerk 4: VC810 Tilt table HP U "M04 VC810 SEQ run HP" U #tmp_seq_cmd_onoff O "HMI KEY".P04.VC810.Manual_Jog_output_HP = #VC810.Support.CMD_HP
U #VC810.Support.CMD_HP U "E04 HC812 B46 HP" UN "E04 VC810 B40 HP" SA "T04 VC810 HP SA" U "T04 VC810 HP SA" = "A04 VC810 Y811 HP" |
|
|
|
|
|
Netzwerk 5: Exit if not manual mode *** ON "M00 Manu CmpltMa run" ON "M04 Enabled" BEB |
|
|
|
|
|
Netzwerk 6: VC810 Tilt table set point HP 0-100% U "A00 Y640 HV HP" SPB m090 L #VC810.Support.speed_HP T "HMI KEY".PRS.YAW280.Int_InOut
L #VC810.Support.pressure_HP T "HMI KEY".PRS.YAW286.Int_InOut BEA |
|
|
|
|
|
Netzwerk 7: VC810 Tilt table set point WP 0-100% m090: L 0 T "HMI KEY".PRS.YAW280.Int_InOut
L #VC810.Support.pressure_WP T "HMI KEY".PRS.YAW286.Int_InOut |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
