OB100 StartUp : "Complete Restart" |
|
|
|
|
|
Network 1: Pre-setting Set points "HMI KEY".SetPoint.PT302_PressureMaintainace := 500.0; // 1 bar "HMI KEY".SetPoint.PT302_PressureHysteresis := 25.0; // 0.025 bar "HMI KEY".SetPoint.PT302_PressureRelease := 150.0; // 0.15 bar "HMI KEY".SetPoint.V204_Steam_Regulating_Factor := 0.27; "DI OUT P02".V204.Support.ManualValue := 80.7; // % "HMI KEY".SetPoint.V205_Glycol_Regulating := 3.5; // Set point difference 2°C actual (T306 - T211) "DI OUT P02".V205.Support.ManualValue := 30.5; // % "HMI KEY".SetPoint.V312_Product_inlet := 73.7; // °C "DI OUT P03".V312.Support.ManualValue := 93.7; // % "HMI KEY".SetPoint.SBT_Level := 50; // % "HMI KEY".SetPoint.PT301_SBT_MinStartLevel := 40; // litter "HMI KEY".SetPoint.G120C_Product_inlet := 20.0; // hl "HMI KEY".SetPoint.G120C_Product_inlet_min := 50.0; // rpm "HMI KEY".SetPoint.G120C_Product_inlet_max := 1480.0; // rpm "HMI KEY".SetPoint.G220C_Heating_cycle := 1080.0; // rpm "HMI KEY".SetPoint.G320C_Product_Outlet := 1200.0; // rpm "HMI KEY".SetPoint.Volume_CIP_SBT_inlet := 87.0; // hL "HMI KEY".SetPoint.Temperature_CIP_Lye := 85.0; // °C actual "HMI KEY".SetPoint.Temperature_CIP_Water := 92.0; // °C actual "HMI KEY".SetPoint.Temperature_Deviation := 7.0; // °C "HMI KEY".SetPoint.Pasteurization_Unit_PU := 10.0; |
|
