FB38 MAN P01 : P01 CEA Hydraulic Press - Manual Mode |
|
|
|
|
|
Netzwerk 19: *** Monitoring manual operation ***
IF NOT #ST_MANU THEN RETURN; ELSIF #MODULE_HP AND NOT #Support.HomPos_REg THEN "M01 Init" := TRUE; END_IF; #Support.HomPos_REg := #MODULE_HP; IF #SUPPORT_SEQ THEN RETURN; END_IF; |
|
|
|
|
|
Netzwerk 20: M01 Oil control pump
IF "HMI KEY".P01.M01.F1_HP THEN "DI OUT P01".M01.DRV.CmdExe_WP := FALSE; ELSIF "HMI KEY".P01.M01.F2_WP THEN "DI OUT P01".M01.DRV.CmdExe_WP := TRUE; END_IF; |
|
|
|
|
|
Netzwerk 21: M02 Main oil pump 1
IF NOT "DI OUT P01".Y01.LampWP OR "M00 HYD OpraTest" THEN "DI OUT P01".M02.DRV.CmdExe_WP := "HMI KEY".P01.M02.F2_WP; END_IF; |
|
|
|
|
|
Netzwerk 22: M03 Main oil pump 2
IF NOT "DI OUT P01".Y01.LampWP OR "M00 HYD OpraTest" THEN "DI OUT P01".M03.DRV.CmdExe_WP := "HMI KEY".P01.M03.F2_WP; END_IF; |
|
|
|
|
|
Netzwerk 23: M04 Stroke limitation motor
"DI OUT P01".M04.DRV.CmdExe_HP := "HMI KEY".P01.M04.F11_Enable_HP AND (#M04.CmdExe_slow_HP OR #M04.CmdExe_fast_HP);
"DI OUT P01".M04.DRV.CmdExe_WP := "HMI KEY".P01.M04.F12_Enable_WP AND (#M04.CmdExe_slow_WP OR #M04.CmdExe_fast_WP); |
|
|
|
|
|
Netzwerk 24: Y01 Oil loading pressure maintenance valve
IF "HMI KEY".P01.Y01.F2_WP AND NOT #Support.Y01_F2_WP_REg THEN "DI OUT P01".Y01.CmdExe_WP := NOT "DI OUT P01".Y01.CmdExe_WP; END_IF; #Support.Y01_F2_WP_REg := "HMI KEY".P01.Y01.F2_WP; |
|
|
|
|
|
Netzwerk 25: Y02 Oil relief pressure maintenance valve
IF "HMI KEY".P01.Y02.F2_WP AND NOT #Support.Y02_F2_WP_REg THEN "DI OUT P01".Y02.CmdExe_WP := NOT "DI OUT P01".Y02.CmdExe_WP; END_IF; #Support.Y02_F2_WP_REg := "HMI KEY".P01.Y02.F2_WP; |
|
|
|
|
|
Netzwerk 26: Y03 Ram pressure less down valve
IF "HMI KEY".P01.Y03.F2_WP AND NOT #Support.Y03_F2_WP_REg THEN "DI OUT P01".Y03.CmdExe_WP := NOT "DI OUT P01".Y03.CmdExe_WP; END_IF; #Support.Y03_F2_WP_REg := "HMI KEY".P01.Y03.F2_WP; |
|
|
|
|
|
Netzwerk 27: Y04 Oil pressure circulation valve
IF "HMI KEY".P01.Y04.F2_WP AND NOT #Support.Y04_F2_WP_REg THEN "DI OUT P01".Y04.CmdExe_WP := NOT "DI OUT P01".Y04.CmdExe_WP; END_IF; #Support.Y04_F2_WP_REg := "HMI KEY".P01.Y04.F2_WP; |
|
|
|
|
|
Netzwerk 28: Y05 Ram oil filling valve
IF "HMI KEY".P01.Y05.F2_WP AND NOT #Support.Y05_F2_WP_REg THEN "DI OUT P01".Y05.CmdExe_WP := NOT "DI OUT P01".Y05.CmdExe_WP; END_IF; #Support.Y05_F2_WP_REg := "HMI KEY".P01.Y05.F2_WP; |
|
|
|
|
|
Netzwerk 29: Y08 Oil pressure standby valve
IF "HMI KEY".P01.Y08.F2_WP AND NOT #Support.Y08_F2_WP_REg THEN "DI OUT P01".Y08.CmdExe_WP := NOT "DI OUT P01".Y08.CmdExe_WP; END_IF; #Support.Y08_F2_WP_REg := "HMI KEY".P01.Y08.F2_WP; |
|
|
|
|
|
Netzwerk 30: C13 Ram safety valve WP_HP
"DI OUT P01".C13.CmdExe_WP := "HMI KEY".P01.C13.F12_Enable_WP AND "HMI KEY".P01.C13.F2_WP XOR ("DIF_Main_Safety_RTG1".FB_SAFE_P01.E00_THC_L_R_CD_1_Q AND NOT "DIF_Main_Safety_RTG1".FB_SAFE_P01.E00_THC_L_R_CD_2_Q);
"DI OUT P01".C13.CmdExe_HP := "HMI KEY".P01.C13.F11_Enable_HP AND "HMI KEY".P01.C13.F1_HP XOR (NOT "E00 Ram CD2 Pb HP" AND "E00 Ram CD1 Pb HP"); |
|
|
|
|
|
Netzwerk 31: Y09 Ram safety valve WP
IF "HMI KEY".P01.Y09.F2_WP AND NOT #Support.Y09_F2_WP_REg THEN "DI OUT P01".Y09.CmdExe_WP := NOT "DI OUT P01".Y09.CmdExe_WP; END_IF; #Support.Y09_F2_WP_REg := "HMI KEY".P01.Y09.F2_WP; |
|
|
|
|
|
Netzwerk 32: C27 Ram stow pin (RSP)
"DI OUT P01".C27.VLV.CmdExe_WP := "HMI KEY".P01.C27.F12_Enable_WP AND NOT "HMI KEY".P01.C27.F1_HP AND ("HMI KEY".P01.C27.F2_WP OR "DI OUT P01".C27.FB_WP);
"DI OUT P01".C27.VLV.CmdExe_HP := "HMI KEY".P01.C27.F11_Enable_HP AND NOT "HMI KEY".P01.C27.F2_WP AND ("HMI KEY".P01.C27.F1_HP OR "DI OUT P01".C27.FB_HP); |
|
|
|
|
|
Netzwerk 33: YF41E Oil volume flow set value 0-100%
IF "HMI KEY".P01.YF41E.F2_WP AND NOT #Support.YF41E_F2_WP_REg THEN "DI OUT P01".YF41E_PAW_VALU.Support.CmdExe_WP := NOT "DI OUT P01".YF41E_PAW_VALU.Support.CmdExe_WP; END_IF; #Support.YF41E_F2_WP_REg := "HMI KEY".P01.YF41E.F2_WP; |
|
|
|
|
|
Netzwerk 34: YP43E Ram rapid traverse down proportion valve
IF "HMI KEY".P01.YP43E.F2_WP AND NOT #Support.YP43E_F2_WP_REg THEN "DI OUT P01".YP43E_PAW_VALU.Support.CmdExe_WP := NOT "DI OUT P01".YP43E_PAW_VALU.Support.CmdExe_WP; END_IF; #Support.YP43E_F2_WP_REg := "HMI KEY".P01.YP43E.F2_WP; |
|
